Are you looking for a professional and easy-to-use PCB Design software with powerful autorouter and reasonable price?
Try DipTrace and you will be surprised! DipTrace is a complete state-of-the-art PCB Design System. It includes:
PCB Layout — PCB design with an easy-to-use manual routing tools, shape-based autorouter and auto-placer.
Schematic — Schematic Capture with multi-level hierarchy and export to PCB Layout, Spice or Netlist.
Component and Pattern Editors — allow you to make new parts and footprints.
Standard Libraries - include 100,000+ parts.
3D PCB Preview - shows your design in 3D. 2500+ package 3D models are supplied with the program.
Import/Export Features - allow you to exchange designs and libraries with other EDA tools.
Step-by-Step Tutorial - learn the software and start real work in a few hours.
Full featured 30-day trial and 300-pin Freeware versions are available for evaluation.
Special Discounts for non-profit users and education.
DipTrace provides the following features:
Easy to learn user interface
To design a schematic, simply select and place components onto your document and connect them together using the wire and bus tools. Multisheet and hierarchical schematics are supported. Then select the menu option 'Convert to PCB' to convert the schematic to PCB. Layout can be updated from Schematic in a few clicks at anytime. When you create or edit design objects they are highlighted to improve your work. Step-by-step tutorial guides you through the design process and allows to get started with ease.
Smart placement and auto-placement features
After converting Schematic to PCB layout, place board outline and arrange components. Then use "placement by list" for chips/connectors and auto-placement for other components to get acceptable result in a few minutes and start routing.
Easy to use manual and powerful automatic routing
DipTrace PCB software includes 2 automatic routers (Shape-based and Grid-based). Shape Router is able to route complex layouts with SMD components as well as single-layer boards. Grid Router can also make single-layer boards with jumper wires. With Specctra DSN/SES interface you can use external shape-based or topological autorouter. Intelligent manual routing tools allow you to create and edit traces by 90, 45 degree or without any limitations. Curved traces are supported. Through, blind or buried vias can be used in automatic and manual routing. Board size is not limited.
Shape-based copper pour
Powerful copper pour system can help to reduce your manufacturing costs by minimizing the amount of etching solution required. To use it, all you have to do is insert a copper area on your board in the PCB Layout program and any pad or trace inside the selected area will be automatically surrounded with a gap of the desired size. Using copper pour you can also create planes and connect them to pads and vias (different thermal types are supported).
Advanced Verification Features
Schematic and PCB design modules have number of verification features that help control project accuracy on different design stages: The ERC function shows possible errors in Schematic pin connections using defined rules and allows you to correct errors step-by-step. DRC function checks the clearance between design objects, minimum size of traces, and drills. Errors are displayed graphically and you can fix them step-by-step and rerun the DRC in one click after any corrections. Net Connectivity Check verifies if all nets of PCB are electrically connected. This feature uses traces, copper pour filled area and shapes to control connectivity, then reports broken and merged nets with area details. Comparing to Schematic allows you to check if routed PCB is identical with Schematic.
3D PCB Preview
DipTrace PCB Layout module includes 3D preview feature which shows you how your completed project will look like. This feature uses hardware graphics acceleration, so you can change colors and rotate/zoom/pan board in real-time. 2500+ package 3D models are available for free and you can use any models in VRML 2.0 or 3DS formats.
With DipTrace Schematic Capture or Component Editor specify spice settings or attach models to the parts. Then export .cir net-list of your Schematic to LT Spice or another simulation software to verify how it works.
Package modules allow you to exchange schematics, layouts and libraries with other EDA and CAD packages (DXF, Eagle, P-CAD, PADS, OrCAD). DipTrace Schematic Capture and PCB Layout also support Accel, Allegro, Mentor, PADS, P-CAD, Protel and Tango netlist formats.
Manufacturing output formats
DipTrace provides support for a number of different manufacturing output formats. Using this PCB software you can produce N/C Drill files for numerically controlled (N.C.) drilling machines and RS-274X Gerber files for sending to board manufacturers. Vectorizing function allows to export true-type fonts and raster images. Also DipTrace supports DXF output.
Producing PCBs using milling method
DipTrace allows you to export edge polylines to DXF. The DXF files can be converted to G-code with Ace Converter (it's free). Before edge exporting the DRC function of pcb layout program checks the design and shows possible problems if exist.
Standard component libraries
DipTrace package includes component and pattern libraries which contain 100,000+ components from different manufacturers.
Creation of your own libraries
Component and Pattern Editors allow to design your own symbols and patterns. To create complete components simply connect them together using Component Editor.
... and much more!
Mar 20, 2013 — version 2.3.1
Oct 19, 2012 — version 2.3
Aug 2, 2012 — version 2.2.9 b
Sep 7, 2011 — version 2.2
Mar 12, 2011 — version 2.1.9 b
DipTrace breaks the traditional mold for schematic capture and layout CAD software by being super-intuitive and simple to learn, while still providing all the capabilities of design packages costing 10 times as much.
